Simulated Annealing模拟退火算法实现，使用Python编程语言
Cardiff School of Computer Science and Informatics
Coursework Assessment Pro-forma
Module Code: CM3109
Module Title: Combinatorial Optimisation
Lecturer: Richard Booth
Assessment Title: Coursework
Assessment Number: 1
Date Set: 9/11/2023
Submission Date and Time: by 7/12/2023 at 9:30am
Feedback return date: 12/1/2024
If you have been granted an extension for Extenuating Circumstances, then the
submission deadline and return date will be later than that stated above. You will be
advised of your revised submission deadline when/if your extension is approved.
If you defer an Autumn or Spring semester assessment, you may fail a module and
have to resit the failed or deferred components.
If you have been granted a deferral for Extenuating Circumstances, then you will be
assessed in the next scheduled assessment period in which assessment for this
module is carried out.
If you have deferred an Autumn or Spring assessment and are eligible to undertake
summer resits, you will complete the deferred assessment in the summer resit
period.
If you are required to repeat the year or have deferred an assessment in the resit
period, you will complete the assessment in the next academic year.
As a general rule, students can only resit 60 failed credits in the summer assessment
period (see section 3.4 of the academic regulations). Those with more than 60 failed
credits (and no more than 100 credits for undergraduate programmes and 105
credits for postgraduate programmes) will be required to repeat the year. There are
some exceptions to this rule and they are applied on a case-by-case basis at the
exam board.
If you are an MSc student, please note that deferring assessments may impact the
start date of your dissertation. This is because you must pass all taught modules
before you can begin your dissertation. If you are an overseas student, any delay may
have consequences for your visa, especially if it is your intention to apply for a post
study work visa after the completion of your programme.
NOTE: The summer resit period is short and support from staff will be minimal.
Therefore, if the number of assessments is high, this can be an intense period of
work.
This assignment is worth 30% of the total marks available for this module. If coursework
is submitted late (and where there are no extenuating circumstances):
1 If the assessment is submitted no later than 24 hours after the deadline,
the mark for the assessment will be capped at the minimum pass mark;
2 If the assessment is submitted more than 24 hours after the deadline, a
mark of 0 will be given for the assessment.
Extensions to the coursework submission date can only be requested using the
Extenuating Circumstances procedure. Only students with approved extenuating
circumstances may use the extenuating circumstances submission deadline. Any
coursework submitted after the initial submission deadline without approved
extenuating circumstances will be treated as late.
More information on the extenuating circumstances procedure and academic regulations
can be found on the Student Intranet:
https://intranet.cardiff.ac.uk/students/study/exams-and-assessment/extenuatingcircumstances
https://intranet.cardiff.ac.uk/students/study/your-rights-and-responsibilities/academicregulations
By submitting this assignment you are accepting the terms of the following declaration:
I hereby declare that my submission (or my contribution to it in the case of group
submissions) is all my own work, that it has not previously been submitted for
assessment and that I have not knowingly allowed it to be copied by another student.
I declare that I have not made unauthorised use of AI chatbots or tools to complete
this work, except where permitted. I understand that deceiving or attempting to
deceive examiners by passing off the work of another writer, as one’s own is
plagiarism. I also understand that plagiarising another’s work or knowingly allowing
another student to plagiarise from my work is against the University regulations and
that doing so will result in loss of marks and possible disciplinary proceedings1.
1 https://intranet.cardiff.ac.uk/students/study/exams-and-assessment/academic-integrity/cheating-andacademic-misconduct
Assignment
The assignment is described in detail in the attachment.
The module content that is required to complete the assessment has already been taught
by the hand-out date, so the assessment can be started immediately on that date.
Learning Outcomes Assessed
Explain the concepts of problem state spaces and search
Criteria for assessment
Credit will be awarded against the following criteria.
- [Correctness] Do the answers correctly address the requirements of each task?
Does the provided code run correctly in Task 2? - [Clarity] Are explanations and summaries easily understandable? Is
documentation clear? Are comments provided in the code to clarify non-standard
code fragments? - [Understanding of concepts] Do the answers show an understanding of basic
optimisation concepts such as neighbourhood?
Feedback and suggestion for future learning
Submission Instructions
You are required to complete 3 tasks about implementing a simulated annealing
algorithm, as described in detail in the attachment. The answers to tasks 1 and 3 should
be submitted as a single pdf file. The answer to task 2 should be submitted as source
code in the programming language you choose to use.
Description Type Name
Task
1+3
Compulsory One PDF (.pdf) file Text_[student number].pdf
Task 2 Compulsory One or more source code files in
the programming language of
choice
No restriction
Feedback on your coursework will address the above criteria. Feedback and marks will
be returned on 12/1/2024 via Learning Central. This will be supplemented with oral
feedback via individual meetings.
Any code submitted will be run on a system equivalent to those available in the Windows
lab and must be submitted as stipulated in the instructions above.
Any deviation from the submission instructions above (including the number and types of
files submitted) may result in a mark of zero for the assessment or question part.
Staff reserve the right to invite students to a meeting to discuss coursework submissions
Support for assessment
Questions about the assessment can be asked on the Discussion Board on the module’s
Learning Central pages, or via email to the module team.
CM3109 Coursework
Autumn semester 2023
Notes before starting
- The following programming exercises may be done using a programming language of your own choice, though all parts should be done
using the same language. If you wish to use anything other than Java
or Python then please let me know well in advance so I can make sure
I have everything necessary to run your program installed on my computer. - If you use any external sources for solving your coursework (e.g. pseudocode from a website), you should add a comment with a reference to
these sources and a brief explanation of how they have been used.
The aim of this coursework is to use simulated annealing to solve an optimisation problem coming from the field of computational social choice – a hot
interdisciplinary topic currently receiving a lot of attention from researchers
in several different fields, including AI. Section 1 provides necessary background to the problem, with the specific coursework tasks coming in Section
2.
1 Background
We start by introducing the problem we’re looking at, then we discuss how
to represent the input and outputs to this problem, and then we introduce
a particular proposal for approaching this problem which we will aim to
implement via simulated annealing.
1
The problem
Suppose we have a competition with n participants, which is decided by
playing a tournament in which each participant plays one match against each
of the others. (These participants could be football teams, chess players, or
anything). After the tournament is finished we know both (i) the winner of
each match (or if it was a draw), and (ii) the margin of victory (represented
by an integer greater than 0 if it wasn’t a draw). The question is, based
on this information, which participant should be judged to be the winner of
the tournament, who is the runner-up, who places third, and so on up to
the worst? In other words, which ranking of the participants (from best to
worst) appropriately reflects the relative quality of the participants? (We do
not allow ties in the ranking).
Weighted tournament graphs and rankings
We can picture such a tournament T as a directed graph whose nodes are
the participants, and such that there exists a directed edge from i to j if i
is the winner of the match “i versus j”. Each such edge is labelled with a
weight w(i, j), which is the number representing the margin of victory. One
example of such a weighted tournament graph is on the left of Fig. 1. (Note
the lack of edge between B and D, indicating their match was drawn.) There
is an edge from A to C labelled with 14, indicating that A was the very clear
winner (by margin 14) of the match “A versus C”. A also defeated B by a
margin of 5, but was defeated by D by a margin of 3. These three results
would suggest that D has claims to being declared the best, but D was itself
defeated quite convincingly by C (by margin of 9), so it’s not clear-cut.
Another way to represent a weighted tournament graph (more amenable
for representation in a computer) is as an n × n matrix [aij ] whose rows and
columns represent the participants {i | i = 1, . . . , n} and whose (i, j) entry
aij equals 0 if i did not defeat j, and gives the weight w(i, j) if i defeated j.
For example, the matrix on the right of Fig. 1 is the matrix representation
of the tournament graph to its left.
Concerning the output of our problem, i.e., rankings, the easiest way to
represent a ranking is as a list [i1, i2, . . . , in] with the first entry i1 representing
the best participant, the second i2 representing the second best, and so on.
For instance, continuing the above example, the ranking which places D first
followed by A, B and C, in that order, would be represented as [D, A, B, C].
2
Figure 1: An example tournament graph with n = 4 participants A, B, C, D
on the left, with its matrix representation on the right
Kemeny rankings
In the above problem, we have to choose the ranking that “best fits” the
results from a given weighted tournament T. Several different proposals have
been made for how to precisely formalise what “best fit” means. We are going
to focus on just one of them, which is based on the intuition of minimising
the disagreements with T. Let’s say a particular ranking R disagrees with T
on an edge (x, y) if x defeats y in T but y is ranked above x in R. We can
then measure how well R fits T by adding up all the weights of all the edges
for which R disagrees with T. This results in the Kemeny score1 of R (with
respect to T), denoted by c(R, T) and given by the following formula:
c(R, T) = �{w(x, y) | R disagrees with T on (x, y)}.
For example if T is the weighted tournament in Fig. 1 and R = [D, A, B, C]
then R disagrees with T on (C, D) and (C, B), which have weights 9 and 2
respectively. Hence c(R, T) = 9 + 2 = 11. The ranking that best fits T is
then taken to be any ranking R that has the lowest possible Kemeny score.
Thus we arrive at the following optimisation problem:
Optimisation problem. Given a weighted tournament T, find a ranking
R that minimises the Kemeny score c(R, T).
A ranking that minimises the Kemeny score (with respect to a given
tournament T) is called a Kemeny ranking (with respect to T). Note that
1Named after John Kemeny.
3
some tournaments can have more than one Kemeny ranking. The tournament
in Fig. 1 has two Kemeny rankings, namely [A, C, B, D] and [A, C, D, B].
2 Coursework questions
The tasks below require you to write a program (in a programming language
of your choice) that is able to read a specific weighted tournament from
a separate file (to be described below), and return a Kemeny ranking for
this tournament – or at least an approximation of one – using simulated
annealing (see Week 5, Video 2 for the pseudocode of the simulated annealing
algorithm).
This coursework will use a particular weighted tournament containing real
data (Formula One 1984.wmg) from the 1984 World Formula One Motor Racing Championship, for which there were a total of 35 participants. This file,
along with an explanation of its data format (see How to read tournament data.pdf)
can be downloaded from Learning Central.
First part: Setting SA parameters
As discussed during lecture, simulated annealing has a number of parameters
that need to be fixed by the programmer in advance (see Week 5 videos
and slides). Some will be fixed below, but for others you will be free to
experiment. - initial solution. For the initial solution you must always use the
ranking [1, 2, 3, 4, . . . , 34, 35], using the numbering of candidates specified in Formula One 1984.wmg. - cooling schedule. For initial temperature TI and temperature length
TL you are free to experiment with different values. Your only restriction regarding cooling ratio f is that f(T) should be of the form
f(T) = a×T, where a is some fixed parameter between 0 and 1 (which
you are free to choose). - cost function. The cost of a solution (i.e., possible ranking) R is
the Kemeny score c(R, T), defined in Section 1 above, where T is the
tournament loaded from Formula One 1984.wmg.
4 - stopping criterion. The algorithm should STOP if a pre-specified
number num non improve of solutions have been looked at without improving on the current best solution. You are free to experiment with
different values of num non improve.
The only parameter not yet specified is the neighbourhood function,
which brings us to…
TASK 1. Write down a definition of a neighbourhood N that is specific to
this problem, i.e., specify the conditions for when any given ranking R2 is
a neighbour of another R1, and illustrate your definition with an example.
Justify your choice of definition by showing how the cost of a neighbouring
solution R2 can easily be computed from the cost of current solution R1.
(Total 5 marks)
Indicative mark breakdown is as follows:
Second part: Implementation
After having set up the parameters, you must now implement the algorithm.
TASK 2. Write a program implementing the simulated annealing algorithm
to find a ranking that minimises the Kemeny score with respect to the given
weighted tournament T specified in Formula One 1984.wmg. You must use
the parameters in accordance with the first part above, and use the neighbourhood you defined in Task 1. Your program should have the following
behaviour.
- It should be executable via the command line, taking the file Formula One 1984.wmg
as an argument. Zero marks will be awarded for Task 2 if it is not executable from the command line.
5 - After running, your program should print to the screen the following
information:
- The best ranking it found (positions 1 to 35), in the form of a
table, using the real names of the candidates, which are included
in Formula One 1984.wmg. - The Kemeny score of this best ranking.
- The algorithm’s runtime in milliseconds.
Your code will be judged on whether the SA algorithm is correctly implemented and, given it is correctly implemented, whether the solution returned
is optimal (or at least close to optimal) and is returned within reasonable
runtime. You must highlight in your code (e.g., with comments) the part that
deals with the actual steps of the SA algorithm. Failure to do so may lead to
loss of marks.
(Total 10 marks)
Indicative mark breakdown is as follows:
Third part: Selecting best parameters and discussion
As stated in the first part, you are free to try out different values for the
parameters TI, TL and the “a” in f(T) = a × T, as well as the number
num non improve in the stopping criterion. The final task is about experimentally tuning to the best choice of parameters and reflecting on your
results.
6
TASK 3. Give the values of the parameters TL, TI and a (in f(T) = a×T),
as well as num non improve, which seem to give the best solutions for your
program. For this “best” choice of parameters provide screenshots of the
output of your program. Write a short summary (max 500 words) of your
results, indicating the range of different values you tried for the parameters,
which parameters’ variation had the biggest effect on the output solution, etc.
Extra marks available for deeper analysis and presentation/visualisation of
results, e.g., via use of graphs showing results of varying the different SA
parameters Also offer some speculation on the presence of local optima in
this problem. Are there many? (Total 10 marks)
Indicative mark breakdown is as follows:
7 - https://www.cardiff.ac.uk/study/undergraduate/courses/course/computer-science-bsc
