2021/6/30 University of Adelaide – 2021 COMP SCI 2207/7207 Web & Database Computing Main Exam
https://adelaide.mobius.cloud/130/316/assignments/1251/0 1/4
Do NOT press Submit Assignment button until you are ready to submit your exam for grading.
Your progress is saved automatically, and you can resume an already started exam if your session resets or browser is
closed.
You can only make one (1) submission in the final exam. Your progress will be submitted automatically on the deadline if you
have not yet submitted.
Part 1 01000103
You have been hired to design a web application for an online shop that sells books.
The system requires the following features:
Users can search the different books available
Books can be searched/filtered by:
Genre/Category
Author
Cover type (hard/soft)
Price
Users can sign-up and log-in
Users can order books
Users can view their order history
Thinking about such a system, complete the following tasks:
Task 1.1
Design a database schema diagram for the system described.
Be sure to include appropriate relationships and cardinalities.
Be sure to normalise the schema to at least 3rd normal form.
Upload the file as an image or pdf
选择文件 未选择任何文件
Allowed Extensions: jpeg jpg pdf png
[30 marks]
Task 1.2
When building a database schema, N-N relationships need to be properly reduced/decomposed.
Briefly discuss how this applies to the system you’ve designed in Task 1.1 and, specifically in terms of your system and its
relationships, explain how this relates to database normalisation.
上传
2021/6/30 University of Adelaide – 2021 COMP SCI 2207/7207 Web & Database Computing Main Exam
https://adelaide.mobius.cloud/130/316/assignments/1251/0 2/4
[10 marks]
Task 1.3
Implement your database schema from Task 1.1 in MySQL
When you create the database
Ensure appropriate tables, data types, keys and integrity constraints are present.
Add at least 1 row of test data to each table.
Download a backup/dump of the database and upload as a zip file
选择文件 未选择任何文件
Allowed Extensions: zip
[30 marks]
Task 1.4
Write a SQL query to retrieve the name and email address of all users who bought a given item in the last 30 days.
You can assume the item’s unique indentifying information is provided.
公式编 辑器
样式 字体 大小
Words: 0
上传
2021/6/30 University of Adelaide – 2021 COMP SCI 2207/7207 Web & Database Computing Main Exam
https://adelaide.mobius.cloud/130/316/assignments/1251/0 3/4
[10 marks]
Task 1.5
Implement a basic web application for the search feature of this online shop.
Use only the technologies covered in this course:
HTML & CSS
JavaScript, AJAX, & basic client-side Vue.js
NodeJS/Express
MySQL
Only implement the search page/feature and any necessary supporting code on the server.
Users should also be able to filter search results by:
Genre/Category
Author
Cover type (hard/soft)
Price
Be sure to follow best practices as discussed throughout the course.
Excluding the node_modules folder, submit/upload your implementation as a zip file
选择文件 未选择任何文件
Allowed Extensions: zip
[160 marks total]
Consisting of
30 marks for functionality
20 marks for HTML & CSS
20 marks for client side JS and Vue
20 marks for AJAX requests
20 marks for server side routes
20 marks for MySQL integration
30 marks for good UX, standard compliance, maintainability & security practices
公式编 辑器
样式 字体 大小
Words: 0
上传
2021/6/30 University of Adelaide – 2021 COMP SCI 2207/7207 Web & Database Computing Main Exam
https://adelaide.mobius.cloud/130/316/assignments/1251/0 4/4
Task 1.6
Dymocks (https://www.dymocks.com.au/books/) is an example of an online shop that sells books.
Identify a feature present in both the Dymocks website, and your implementation from Task 1.5.
Specifically in terms of perceivability and operability, discuss how these two systems compare.
[15 marks]
公式编 辑器
样式 字体 大小
Words: 0
